CP PLUS CP-UVR-0401E1V-I 4 Channel 1080N Digital Video Recorder

The CP PLUS CP-UVR-0401E1V-I is a compact and versatile 4 Channel Digital Video Recorder (DVR) designed for reliable CCTV surveillance in homes, offices, shops, warehouses, commercial establishments and other security applications. It supports multiple camera technologies including HDCVI, AHD, TVI and CVBS, making it suitable for both new CCTV installations and system upgrades.

With support for up to 5 IP camera inputs, this hybrid DVR provides greater flexibility for surveillance installations. It can accommodate compatible IP cameras alongside analog CCTV cameras, allowing users to build or expand their security system according to their requirements.

Hybrid Multi-Format Camera Support

The CP-UVR-0401E1V-I supports HDCVI, AHD, TVI and CVBS analog camera technologies, helping users connect cameras from different compatible platforms. It also supports IP camera connectivity, making the recorder a practical choice for hybrid CCTV systems.

The recorder supports up to 5 IP camera channels and compatible IP cameras with resolutions of up to 2MP per channel, providing flexibility when expanding an existing surveillance network.

Efficient Video Recording with H.265 Compression

The DVR incorporates modern video compression technologies including AI Coding, InstaStream, H.265, H.264+ and H.264. These technologies help optimize video storage and network bandwidth while maintaining useful surveillance image quality.

Efficient compression can help reduce the amount of storage space required for recorded footage, making the DVR suitable for installations where continuous recording and longer retention periods are required.

AI Coding and Intelligent Motion Detection

The AI Coding technology helps optimize video encoding by efficiently allocating bandwidth and storage resources.

The DVR also supports IMD+ (Intelligent Motion Detection Plus) functionality, helping distinguish relevant human and vehicle movement from ordinary motion in supported configurations. This can make surveillance monitoring more practical by reducing unnecessary motion events.

Up to 6TB HDD Storage Support

The CP PLUS CP-UVR-0401E1V-I features one SATA HDD interface and supports a hard drive of up to 6TB capacity. Storage capacity can be selected according to the number of cameras, recording resolution, recording mode and desired video retention period.

The DVR can therefore be configured for applications requiring local recording and playback of CCTV footage.

HDMI and VGA Video Output

For convenient local monitoring, the recorder provides both HDMI and VGA video outputs. A compatible monitor or television can be connected to view live CCTV feeds, playback recorded footage and access DVR configuration settings.

Two-Way Audio Support

The DVR supports two-way audio on up to 4 channels over coaxial connectivity, when used with compatible cameras and audio equipment. This feature can be useful for surveillance applications requiring audio communication or monitoring.

Remote CCTV Monitoring

The CP-UVR-0401E1V-I supports network connectivity through its 10/100 Mbps RJ45 Ethernet interface, allowing the DVR to be connected to a network for remote surveillance and management.

Compatible mobile applications such as iCMOB and gCMOB can be used for remote monitoring, depending on the supported software configuration and network setup. Users can monitor connected cameras remotely and access supported DVR functions from compatible devices.

USB Backup and Connectivity

The recorder is equipped with 2 USB 2.0 ports, providing connectivity for compatible USB devices and backup operations. Recorded surveillance footage can be backed up to a compatible USB storage device for archiving or further review.

Compact Design

With dimensions of approximately 197 × 204.3 × 41.5 mm and a net weight of approximately 540 grams, the DVR has a compact form factor that makes it convenient to install in CCTV cabinets, desks, counters or other suitable locations.

Suitable for Multiple Applications

The CP PLUS CP-UVR-0401E1V-I can be used for a variety of surveillance applications, including:

1. Homes and apartments
2. Retail shops and showrooms
3. Offices and commercial establishments
4. Warehouses and storage facilities
5. Small businesses
6. Schools and institutions
7. Hotels and hospitality establishments
8. Clinics and healthcare premises
9. Small industrial installations
10. Existing CCTV system upgrades

Key Highlights

1. 4 Channel 1080N Digital Video Recorder
2. Supports HDCVI / AHD / TVI / CVBS
3. Supports IP camera connectivity
4. Up to 5-channel IP camera input
5. Supports compatible IP cameras up to 2MP
6. AI Coding for efficient video encoding
7. IMD+ intelligent motion detection functionality
8. Supports H.265 / H.264+ / H.264
9. 1 SATA HDD interface
10. Supports up to 6TB HDD
11. HDMI + VGA video output
12. Up to 4-channel two-way audio over coaxial
13. 1 × RJ45 10/100 Mbps network port
14. 2 × USB 2.0 ports
15. Remote monitoring support through compatible iCMOB / gCMOB applications
16. Compact and lightweight design
17. Suitable for residential and commercial CCTV surveillance

Technical Specifications

Note: Camera, HDD, monitor, network equipment and other accessories may need to be purchased separately. Actual supported functions can vary depending on connected camera models, firmware and system configuration.
